| Specification | Value |
|---|---|
| Frequency Range | 87.50MHz～108MHz, step 10KHz |
| Output Power | 0~500W continuously adjustable |
| Carrier Frequency Precision | ±200Hz |
| Output Power Tolerance | ±1dB |
| Output Impedance | 50Ω |
| RF Output Connector | 7/16′ DIN (L29) – female |
| Residual Wave Radiation | < -70dB |
| Parasitic Amplitude Modulation Noise | < -50dB |
| Operating Environment Temperature | -10℃ ~ +45℃ |
| 38KHz Residual Component in S Signal | < -50dB |
| Audio Pre-emphasis | 0μs / 25μs / 50μs / 75μs optional |
| Signal-to-Noise Ratio | ≥92dB (1kHz, 100% modulation) |
| Stereo Separation | ≥73dB (L → R, R → L) |
| Distortion | ≤0.01% (30Hz ~ 120kHz, 100% modulation) |
| Frequency Response | ±0.01dB (no emphasis, no de-emphasis) |
| Left and Right Channel Level Difference | ≤0.01dB (100% modulation) |
| Power Supply Voltage | 100VAC~265VAC / 47Hz~63Hz |
| Size | 2U (width 18in × height 3.5in × depth 18.9in) |
| Weight | 13Kg (including packaging) |
